Tản Nhiệt Khí Noctua NH-L12S

Notes and warnings

The NH-L12S is a low-profile quiet cooler designed for use in Small Form Factor cases and HTPC environments. While it provides first-rate performance in its class, it is not suitable for overclocking and should be used with care on CPUs with more than 95W TDP (Thermal Design Power). Please consult our CPU compatibility list and TDP guidelines to find out whether the NH-L12S is recommended for your CPU.

Socket compatibility

Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+ (backplate required)

Height (without fan)

70 mm

Width (without fan)

128 mm

Depth (without fan)

146 mm

Weight (without fan)

390 g

Height (with fan)

70 mm

Width (with fan)

128 mm

Depth (with fan)

146 mm

Weight (with fan)

520 g

Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating

Max. TDP

see CPU compatibility list

Fan compatibility

120x120x15 & 120x120x25

Scope of delivery

• 1x NF-A12x15 PWM premium fan
• Low-Noise Adaptor (L.N.A.)
• NT-H1 high-grade thermal compound
• SecuFirm2™ mounting kit
• Noctua metal case-badge

Warranty

6 Years

Model

1x Noctua NF-A12x15 PWM

Bearing

SSO2

Max. rotational speed (+/- 10%)

1850 RPM

Max. rotational speed with L.N.A. (+/- 10%)

1400 RPM

Min. rotational speed (PWM, +/-20%)

450 RPM

Max. airflow

94,2 m³/h

Max. airflow with L.N.A.

70,8 m³/h

Max. acoustical noise

23,9 dB(A)

Max. acoustical noise with L.N.A.

16,8 dB(A)

Input power

1,56 W

Voltage range

12 V

MTTF

> 150.000 h
