Mini PC - Asrock DeskMini X300 Series (Barebone)

Mã sản phẩm

DeskMini X300 Barebone

Chíp xử lý

Supports AMD AM4 Socket CPUs (Cezanne, Renoir, Picasso, Raven Ridge, up to 65W)

Cooler

Supports AMD AM4 CPU Cooler (Max. Height ≦ 46mm)

Memory

- Supports 2 x SO-DIMM DDR4 Memory, Max. 64GB
- AMD Ryzen 5000/4000 series – 3200MHz
- AMD Ryzen 3000/2000 series – 2933MHz

Chipset

- AMD X300

Graphics Output

- HDMI(4K @60Hz)
- DisplayPort, D-Sub

Audio

 1 x Head Phone with MIC Jack, 1 x MIC-In (RealtekALC233)

Front USB

- 1 x USB 3.2 Gen1 Type-C, 1 x USB 3.2 Gen1 Type-A

Rear USB

1 x USB 3.2 Gen1 Type-A, 1 x USB 2.0 Type-A,

Storage

- 2 x SATA 6Gb 2.5-inch 7mm/9.5mm Hard Drive (RAID 0/1)
- 1 x Ultra M.2 (2280) PCIe Gen3 x4 SSD Slot
- 1 x Ultra M.2 (2280) Slot
- PCIe Gen3 x4 (Renoir, Picasso and Raven Ridge APU)
- PCIe Gen3 x2 (Athlon 2xxGE series APU)

LAN

Gigabit LAN (RealtekRTL8111H)

WLAN

 1 x M.2 (key E 2230) Slot for Wi-Fi + BT Module

Connectors

- 1 x USB 2.0 Header
- 1 x Front Panel Header
- 2 x 4-Pin fan connectors (CPU, SYS)
- 1 x DC-In Jack (Supports 19V Power Adapters)
- 1 x Internal Speaker Header (4-Pin)
- 1 x Chassis Intrusion Header (2-Pin)
- 1 x Audio Header (4-Pin)

Accessory

- 2 x SATA Data with Power Cable
- 1 x 120W/19V adapter
- 1 x Screws Pack

Dimension

 155 x 155 x 80 mm (1.92L)

OS

Microsoft Windows 10 64-bit / 11 64-bit

Remark

DeskMini X300 Series don't support S3 function
